16mm Waterproof LED Push Button Momentary Switch 12V–24V Metal
16mm Waterproof LED Push Button Momentary Switch 12V–24V Metal
16mm Waterproof LED Metal Push Button Momentary Switch — 12V to 24V
Upgrade your vehicle, marine vessel, industrial panel, or custom electronics project with this heavy-duty 16mm Waterproof LED Power Push Button Momentary Switch. Built from solid brass with an IP55-rated waterproof housing, this compact yet robust switch is engineered to handle demanding environments — indoors or out. The integrated LED indicator provides instant visual confirmation of your switch state, making it ideal for dashboards, control panels, engine bays, and more.
Key Features
- Model: PBS-33B — 16mm panel mount diameter
- Momentary ON/OFF action — returns to neutral position after each press
- LED illuminated — bright indicator for easy visibility in low-light conditions
- Waterproof rated IP55 — protected against dust ingress and water jets
- Solid brass construction — durable, corrosion-resistant metal body
- Wide voltage compatibility: DC 6V / 12V / 24V / 48V / 110V / 220V / 440V; AC up to 660V
- Operating temperature: -25°C to +40°C
- Mechanical lifespan: up to 1,000,000 (100 × 10⁴) cycles
- Dielectric strength: >1500VAC / 1 min
- Insulation resistance: >10 MΩ
- Rated current & voltage: 3A 250V / 6A 125VAC
Technical Specifications
| Mounting Diameter | 16mm |
| Material | Brass |
| Protection Rating | IP55 |
| Ambient Temperature | -25°C ~ +40°C |
| Altitude | Less than 2000m |
| Relative Humidity | Less than 90% |
| Pollution Level | Class 3 |
| Switch Rating (AC) | 36V/10A · 110V/10A · 220V/5A · 380V/2.7A · 660V/1.8A |
| Switch Rating (DC) | 6V–48V/4A · 110V/2A · 220V/1A · 440V/0.6A |
| Heating Current | 1th 10A |
What's in the Box?
- 1 × 16mm Waterproof LED Power Push Button Momentary Switch (PBS-33B)
Perfect For
- Automotive & marine dashboard panels
- DIY electronics and custom control boxes
- Industrial machinery and equipment panels
- Home automation projects
- Motorcycle, truck, and off-road vehicle builds
Made in Mainland China.
Looking to complete your toolkit or explore more wiring and hardware accessories? Check out our 1/2" Drive 8-Piece Hex Short Socket Set – Vanadium Steel or our 10-Pc Hex Nut & Bolt Extractor Kit 9–19mm for your next project.
Learn more: OSHA on eye and face protection
Frequently Asked Questions
Q: What does "momentary" mean for this 16mm push button switch?
A: A momentary switch is only active (ON) while the button is physically held down. As soon as you release it, the circuit returns to its default OFF state. This makes the 16mm momentary push button ideal for starter buttons, horn buttons, and trigger-style control applications where you only need a brief electrical connection.
Q: Is this LED push button switch compatible with 12V car and truck systems?
A: Yes! This switch is rated for DC 12V and DC 24V, making it fully compatible with standard automotive 12V and heavy-vehicle 24V electrical systems. Its IP55 waterproof rating also means it can be mounted in engine bays, on exterior panels, or in other environments where moisture and dust are a concern.
Q: What panel hole size is needed to install the 16mm push button switch?
A: You need a 16mm diameter hole in your panel for installation. The brass metal body threads securely into the hole with the included nut, ensuring a firm, vibration-resistant mount on dashboards, control enclosures, or custom project panels.
Production & Packaging Notice
To maintain high stock availability and fast shipping times, our items are sourced from multiple verified manufacturing facilities. While the core quality, materials, and product specifications remain identical, you may notice slight variations in the packaging design, manufacturing origin, or the wording of the printed instructions.
