60V 15Ah 16s4p 18650 Lithium Battery Pack with BMS for Motorcycle, Scooter & E-Bicycle
Power your electric ride with confidence using this high-capacity 60V 15000mAh Lithium-Ion Battery Pack. Built with premium 18650 cells in a robust 16s4p configuration, this pack delivers stable, long-lasting energy for e-motorcycles, scooters, and electric bicycles running up to 2000W motors. The integrated high-current BMS (Battery Management System) keeps every ride safe and efficient.
Made in Mainland China.
Why Choose This 60V Lithium Battery Pack?
- High Capacity: 15,000mAh (15Ah) for extended range on a single charge
- Smart BMS Protection: Built-in BMS guards against overcharge, over-discharge, overcurrent, short circuit, and includes automatic charge equalization
- Up to 1,000 Charge Cycles: Long service life means fewer replacements and better value
- CE Certified: Meets international safety and performance standards
- Compact & Lightweight Design: Dimensions of 296×85×70mm and only 2,790g for easy installation
- Wide Temperature Range: Charges from 0–45°C and discharges from -20–65°C for all-season reliability
- Fast Charging Capable: Standard 10-hour charge or fast-charge in as little as 4 hours at 5A
Full Technical Specifications
| Battery Model | 60V 15Ah (16s4p) |
| Cell Type | 18650 Lithium-Ion |
| Nominal Voltage | 60V |
| Nominal Capacity | 15,000mAh |
| Charge Cutoff Voltage | 67.2V |
| Discharge Cutoff Voltage | 48V ± 1V |
| Rated Discharge Current | 40A |
| Max Continuous Discharge Current | 40A |
| Instantaneous Max Discharge Current | 80A |
| Max Continuous Charge Current | 10A |
| Standard Charge Current | 2A (approx. 10 hours) |
| Fast Charge Current | 5A (approx. 4 hours) |
| Charge Mode | CC-CV |
| Cell Source Resistance | <40mΩ |
| Life Cycles | ≥1,000 cycles |
| Supported Motor Power | 1000–2000W |
| Charge Temperature Range | 0°C to 45°C |
| Discharge Temperature Range | -20°C to 65°C |
| Dimensions | 296 × 85 × 70mm |
| Weight | 2,790g |
| Certification | CE |
Compatible Applications
This versatile battery pack is designed to fit a wide range of electric vehicles and applications:
- Electric Motorcycles
- Electric Scooters
- E-Bicycles & E-Bikes
- 2000W Electric Motor Systems
Related Products You May Like
- 10-Pc Hex Nut & Bolt Extractor Kit 9–19mm | HIP Tools
- 105° Right Angle Driver with 1/4" Hex Screwdriver Bit | HIP
Learn more: EPA guidance on lithium-ion battery handling
Frequently Asked Questions
Q: Is this 60V 15Ah lithium battery pack compatible with 2000W electric motors?
A: Yes. This 60V 15000mAh battery pack is specifically designed to support motor systems rated between 1000W and 2000W, making it ideal for high-performance electric motorcycles, scooters, and e-bicycles.
Q: What protections does the built-in BMS provide?
A: The integrated high-current BMS (Battery Management System) provides comprehensive protection including overcharge protection, over-discharge protection, overcurrent protection, short-circuit protection, and automatic charge equalization — keeping your battery and vehicle electronics safe at all times.
Q: How long does it take to fully charge this battery pack?
A: Using the standard 2A charge current, a full charge takes approximately 10 hours. With the fast charge option at 5A, you can achieve a full charge in around 4 hours. The battery uses a CC-CV (Constant Current – Constant Voltage) charging mode for safe and efficient charging.
Q: What is the expected lifespan of this 16s4p battery pack?
A: This lithium-ion battery pack is rated for at least 1,000 charge-discharge cycles under normal use conditions, offering a long and reliable service life for your electric vehicle.
