AS5600 Magnetic Encoder 12-Bit Angle Sensor Module | I²C

AS5600 Magnetic Encoder – 12-Bit High-Precision Angle Sensor Module

The AS5600 Magnetic Encoder Module delivers 12-bit high-resolution, contactless angle measurement using advanced magnetic induction technology. Whether you're building robotics, motor control systems, CNC machines, or DIY electronics projects, this compact sensor module provides accurate and reliable rotational position data without physical contact — reducing wear and improving longevity.

Its ultra-compact form factor (approximately 2.5 × 2.5 × 0.4 cm) makes it an ideal drop-in solution for space-constrained designs. The AS5600 chip communicates via I²C interface and outputs 12-bit absolute angle data, giving you 4096 positions per revolution for exceptional measurement granularity.

Key Features

• 12-Bit Resolution: 4096 distinct positions per full revolution for high-precision angle tracking
• Contactless Magnetic Sensing: No mechanical wear — long service life in demanding applications
• I²C Interface: Easy integration with Arduino, STM32, Raspberry Pi, and other microcontrollers
• Compact Size: Approx. 2.5 × 2.5 × 0.4 cm (0.98 × 0.98 × 0.16 in) — fits tight spaces
• Portable & Lightweight: Perfect for embedded and wearable electronic projects
• Brand New & High Quality: 100% new components with reliable performance
• Flexible Quantity Options: Available in 1, 2, or 3-piece packs to suit your project needs

Specifications

• Sensor IC: AS5600
• Resolution: 12-bit (4096 positions/revolution)
• Interface: I²C
• Module Dimensions: ~2.5 × 2.5 × 0.4 cm / 0.98 × 0.98 × 0.16 in
• Package Included: 1 / 2 / 3 Pcs (as selected)
• Made in: Mainland China

What's in the Box

• 1 / 2 / 3 × AS5600 Magnetic Encoder Sensor Module (quantity as ordered)

Compatible Projects & Applications

• Robotics joint angle sensing
• Brushless motor (BLDC) position feedback
• CNC axis position tracking
• Gimbal and stabilizer control
• 3D printers and servo systems
• DIY electronics and maker projects

Looking for more electronics tools and project essentials? Check out our 1/2" Drive 8-Piece Hex Short Socket Set – Vanadium Steel or browse our 10-Piece Gardening Tool Kit for your next project.

Note: Due to manual measurement, there may be a deviation of up to 5 mm. Slight color differences between product images and the actual item may occur due to lighting conditions.

Learn more: OSHA on eye and face protection

Frequently Asked Questions

Q: What microcontrollers are compatible with the AS5600 Magnetic Encoder Module?

A: The AS5600 Magnetic Encoder Module uses a standard I²C interface, making it compatible with a wide range of microcontrollers including Arduino (Uno, Mega, Nano), STM32, ESP32, ESP8266, and Raspberry Pi. Any platform that supports I²C communication can interface with this sensor.

Q: Does the AS5600 module require a magnet to function?

A: Yes, the AS5600 is a contactless magnetic sensor that requires a diametrically magnetized permanent magnet (typically a small disc or ring magnet) placed above or below the sensor IC. The magnet is not included with the module and must be sourced separately to match your mechanical design.

Q: How many positions per revolution does the 12-bit encoder provide?

A: With 12-bit resolution, the AS5600 provides 4096 distinct positions per full 360° revolution, giving you extremely fine-grained angle measurement ideal for precision motor control, robotics, and positioning systems.

Q: Can I order multiple units at once?

A: Yes! This listing is available in packs of 1, 2, or 3 modules. Simply select the quantity that best suits your project requirements at checkout.
