Isolated RS485 Level Converter Module 3.3V 5V TTL 2Mbps

Isolated RS485 Level Converter Module – 3.3V/5V TTL Input, 2Mbps, Gold-Plated Pads

Upgrade your embedded or industrial communication setup with this fully isolated RS485 level converter module. Supporting both 3.3V and 5V TTL logic levels and capable of transmitting at speeds up to 2Mbps, this compact module is engineered for developers, automation professionals, and electronics engineers who demand fast, stable, and noise-immune serial communication.

The built-in galvanic isolation protects your host system from ground loops and voltage spikes, while the onboard TVS protection guards against transient surges — making it equally at home in electrically noisy factory environments and precision data acquisition setups. Gold-plated semi-immersion PCB pads ensure a secure, corrosion-resistant solder connection every time.

Key Features

• Dual Voltage Support: Compatible with both 3.3V and 5V TTL logic — no level-shifting adapters needed
• High-Speed Communication: Up to 2Mbps data rate for demanding industrial and automation applications
• Full Galvanic Isolation: Protects host circuitry from ground loops, surges, and electrical interference
• TVS Surge Protection: Industrial-grade transient voltage suppression on RS485 lines
• Gold-Plated PCB Pads: Durable semi-immersion gold contacts for reliable soldering and long-term connectivity
• Built-in Bus Termination: Onboard 120Ω balancing resistor for stable RS485 differential signaling
• Compact Form Factor: 34 × 18 × 9 mm ABS housing fits easily in space-constrained enclosures
• Standard Pinout: 2.54 mm solderable pin header and 5.08 mm KF301-compatible RS485 terminal

Specifications

Ideal Applications

• Industrial automation control systems
• Remote sensor and monitoring networks
• Data acquisition and logging systems
• Embedded systems with UART/TTL serial output
• Smart home and building automation controllers
• Robotics and PLC communication interfaces

Package Contents

• 1 × Isolated RS485 Level Converter Module (DC 3.3V/5V)
